PLC Automatic Matcha Ball Mill DL-6CQM-40PLC Industrial Tea Grinding Machine

Category

DL-6CQM-40 tea ball mill supports manual knob control and intelligent PLC programming control. It crushes and grinds all kinds of tea leaves including green tea, black tea, oolong tea and white tea into ultra-fine matcha powder, with over 70.16% powder reaching 800 mesh. Suitable for small, medium and large matcha processing factories with adjustable fineness requirements.

CHAT ON WHATSAPP
plc球磨机

1. Product Overview

DL-6CQM-40 single tea ball mill is professional industrial grinding equipment customized for mass matcha production. It adopts rotary cylinder ball milling principle to realize staged crushing & fine grinding. High rotation speed delivers strong impact force to break large tea fragments in the early stage; low speed strengthens friction grinding to refine powder in the later stage, greatly improving matcha fineness.

Two control versions are available: conventional mechanical knob version & intelligent PLC programmable control version, flexible for different factory operation demands. The machine is fully stainless steel structure, hygienic and durable, widely applied to all tea varieties grinding.

2. Working Principle

The cylinder rotates at variable speed, lifting grinding balls to high position then free falling to generate impact force for coarse crushing tea raw materials. Meanwhile, friction between grinding balls continuously refines tea powder.
  • Early stage: High speed → impact crushing to break tea blocks
  • Late stage: Low speed → friction grinding to make ultra-fine matcha

    Friction grinding plays a decisive role in improving powder fineness.

3. Application Scenarios

  • Large, medium & small matcha processing factories
  • Factories requiring independent adjustable matcha fineness
  • Food processing plants for green tea, black tea, oolong tea, white tea fine powder making

    Wide Compatibility: Works well with green tea, black tea, oolong tea, white tea and most tea varieties.

4. Core Advantages

  1. Two Control Versions Optional

    Mechanical knob manual regulation & intelligent PLC programmable automatic control, meet manual workshop & automatic production line demands.

  2. Staged Variable Speed Grinding Technology

    Separate coarse crushing & fine grinding, stable powder quality, high 800-mesh finished product ratio ≥70.16%.

  3. Universal Tea Adaptability

    Not limited to raw tea types, supports green tea, black tea, oolong tea, white tea grinding.

  4. Commercial Batch Production Capacity

    20~25kg per batch, stable continuous operation for factory mass production.

  5. Food-Grade Stainless Steel Body

    Corrosion resistant, easy cleaning, compliant with food processing hygiene standards.

  6. Stable Structure & Long Service Life

    Rational cylinder design, low failure rate, suitable for long-time non-stop industrial work.

Model

DL-6CQM-40PLC
Overall Dimension

1500×1190×1760 mm
Power Supply

380V, 50/60Hz
Total Power

1.75 KW
Inner Cylinder Diameter

Φ65 cm
Cylinder Rotation Speed

0~38 rpm programmable adjustable
Grinding Balls Weight

90~100 kg
Single Batch Feeding Capacity

20~25 kg
Control Mode

PLC Intelligent Programmable Panel
800 Mesh Matcha Proportion

≥70.16%
